Scan 1000 Series

The discreet and exclusive built-in models Scan 1003, 1004, 1005 and 1006 are available with black glass doors. A cool glass handle on the door completes the pure expression and separates the model from its competitors on the market. The insert optimises the heat and gives you a wide-screen view of the fire.

Scan 1005 and 1006 both have the same beautiful design, smart design and the same good firing properties. What distinguish the models from each other is that the 1006 has a 15cm wider insight into flames.

These fireplaces are perfect if you want to install a new fireplace into existing open fireplace.

All details are well thought out—even emptying the ash drawer is easy with an integrated ash drawer. Ventilation grills adapted to the product are available in black and white paint.

£3,065.00

Scan 1000 Series

£3,065.00

  • Scan 1003 takes logs up to 50cm, and Scan 1004 takes logs up to 65cm.
  • Scan 1005 and 1006 have the same beautiful design, smart solutions and good firing properties. What distinguishes the models is that the Scan 1006 has a 15 cm wider insight into the flames.

Specifications – Scan 1003

Energy Performance Labelling A
Brand Scan
Model Scan 1003
Output KW 7.2Kw
Efficiency 80%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 566 x W 650 x D 438 mm
Weight 103kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

Specifications – Scan 1004

Energy Performance Labelling A+
Brand Scan
Model Scan 1004
Output KW 8Kw
Efficiency 81%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 570 x W 800 x D 438 mm
Weight 108kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

Specifications – Scan 1005

Energy Performance Labelling A+
Brand Scan
Model Scan 1005
Output KW 6Kw
Efficiency 84%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 470 x W 650 x D 438 mm
Weight 99kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

Specifications – Scan 1006

Energy Performance Labelling A+
Brand Scan
Model Scan 1006
Output KW 7Kw
Efficiency 82%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 470 x W 800x D 438 mm
Weight 116kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

1003-1004 Instruction for Installation and Use

1005-1006 Instruction for Installation and Use

1003 Product Dimensions

1004 Product Dimensions

1005 Product Dimensions

1006 Product Dimensions

  • Scan 1003 takes logs up to 50cm, and Scan 1004 takes logs up to 65cm.
  • Scan 1005 and 1006 have the same beautiful design, smart solutions and good firing properties. What distinguishes the models is that the Scan 1006 has a 15 cm wider insight into the flames.

Specifications – Scan 1003

Energy Performance Labelling A
Brand Scan
Model Scan 1003
Output KW 7.2Kw
Efficiency 80%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 566 x W 650 x D 438 mm
Weight 103kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

Specifications – Scan 1004

Energy Performance Labelling A+
Brand Scan
Model Scan 1004
Output KW 8Kw
Efficiency 81%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 570 x W 800 x D 438 mm
Weight 108kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

Specifications – Scan 1005

Energy Performance Labelling A+
Brand Scan
Model Scan 1005
Output KW 6Kw
Efficiency 84%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 470 x W 650 x D 438 mm
Weight 99kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

Specifications – Scan 1006

Energy Performance Labelling A+
Brand Scan
Model Scan 1006
Output KW 7Kw
Efficiency 82%
CO Emissions 0.07%
Style Modern Stoves
Flue size 148mm
Fuel Wood
Dimensions H 470 x W 800x D 438 mm
Weight 116kg
Material Steel and Cast Iron
Eco Design Yes
DEFRA Yes

1003-1004 Instruction for Installation and Use

1005-1006 Instruction for Installation and Use

1003 Product Dimensions

1004 Product Dimensions

1005 Product Dimensions

1006 Product Dimensions
